Where only the total amounts are given, try to purchase in lengths as long as possible to minimize wastage. When cutting the frame members, cut the longest members first, then cut the shorter pieces from the off-cuts to avoid wastage.
On the following pages you will find a complete set of building plans with graphic representations, elevation drawings, work in progress photos, a complete building materials list, templates, and an explanation of how to assemble this building on your own. For Starters: You will need access to a circular saw, chalk box, tape measure, speed square , hammer, ladder.
Note: If you've bought pre-hung windows for the coop, install them following the manufacturer's directions. I would like to add a window over the nest box and two windows, one on either side of the door. This basic plan can be modified to suit any size coop you wish to build; the only changes you have to make are the measurements.
Usually the width of a window frame should be the same as the thickness of the wall, including the interior lining and the exterior siding. This is so the frame will be flush with both the inside and outside of the wall allowing for trims and moldings to fit neatly around both the inside and outside of the window. NOTE: This complete plan-set can also be purchased in downloadable PDF format free of advertising and print friendly for only $5.
With Instructables you can share what you make with the world, and tap into an ever-growing community of creative experts. As the person who filed the permit, you are the main contractor and responsible for the building.
You should consider your tools for completing the job before you begin in order to save time and money. Now that the basics of framing are understood, take a look at the sample diagrams for my framing. Shingling is by far the hardest part of roofing and can be hellish in the heat and sun of summer. With the building sheathed and the roof shingled, you will want to put in the windows and doors to complete the illusion of a completed project.
Just wondering if you had checked into metal roofing (like I've seen installed on primitive cabins).
Set the floor frame on top of the skids and measure the diagonals to make sure it's square. Install the tongue-and-groove floor sheathing, starting with a full sheet at one corner of the frame. Cut the 2 ? 4 wall plates: four at 144" for the side walls and four at 89" for the front and back walls. Cut three 2 ? 4 rafter ties at 96", and clip the top outer corners so they won't project above the rafters. Cut holes for four soffit vents: locate one vent in each of the two outer rafter bays, along the eave, on both sides of the building.


Install the hinges and hang the door, using shims to set the gaps at the bottom and top of each door. Install flashing above the door, nail-off the siding, then install the 1 x 4 door trim, using 8d galv. Install each window frame in its rough opening, using shims and a level to make sure the frame is plumb and level and the jambs are straight. Install the glass and outer stops, applying glazing tape to the stops on both sides of the glass. Install the 1 x 4 corner trim so that it butts against the horizontal trim and extends to the bottom edges of the siding.
Determine the best slope for the ramp using boards or plywood set on the ground and the shed floor.
Measure the distance from the ground to the shed floor; subtract 2" from that dimension to get the height of the tapered stringers.
Cut 2 x 4s for the ramp decking-the number needed depends on the length of the sloping sides of the stringers. I want to add to the run and increase the size from it's current 12x18 to 15x20 and add netting over the top. It consists of head, sill and two side jambs forming a box or rectangle to which the sash (moving segment of the window) is attached.
Is it safe to use a 12 foot 2x4 wall with the ridge pole on top of that and install the rafters to just one half. I have framed a couple small additions to my cabin in the past, using a framing book for guidance. I decided they needed a large building that would provide shelter, a safe place to sleep, and a place for them to leave my eggs.
Test-fit the rafters using a 2 ? 4 spacer block, then cut the remaining twelve common rafters.
Reinforce the rafter-wall connection with metal anchors-install them on all but the outer common rafters.
End nail the lookouts to each of the inner overhang rafters, using 16" on-center spacing (see the GABLE OVERHANG DETAIL). Keep the ends flush with the outsides of the overhang rafters, and the bottom edges flush with the bottom rafter edges; use 16d nails. For each door, fit together six boards with their ends flush, then mark the two end boards for trimming so that the total width is 30". Cut the tapered stringers from 2 x 8 lumber: cut one for each end and one for every 16" to 24" in between.
I put the hardwire inside to keep the birds off the window sill and to allow a plywood cover to be framed forming a tight seal during the winter. I wanted exterior nest boxes to help save interior space, I framed the nest boxes just as I framed the walls except I turned the finished framing on its side and screwed the bottom plates to the wall framing.
I added pieces of 2x4 on the exterior wall and attached 2x4's to the top of the scraps lying flat.


I cut 2x4's at 74 inches and cut a 45 degree angle on both corners, I did the same on 29" 2x4s, I saved the cut off ends and used those as a support for the corners of the framing. After the chicks are ready to integrate with the older members of the flock I need to add the pop door and ladder. I will be looking at your pages ALOT as I am constructing my own coop with little to no building experience! Before you can do anything else you need to get another inspection of the rough framing and construction.
Face nail each tie end to the rafter with three 10d nails, then toenail each tie end to the top wall plate with two 8d nails.
I then used wood screws to attach the 2x4's to the 2x6; taking care to assure the roosts were level.
The construction company has to pay to dump the scraps in a landfill; you will be helping them save some money while getting the things you need and helping to save the environment. Now I needed to figure out how I was going to build this building and what modifications I needed to make for the birds. At the gable ends, install Z-flashing along the top edge of siding, then continue the siding up to the soffits. I took a long 2x4 and cut the same angle as the roof then put it on top of the nest box framing. Shop around; know what the going rate is for your materials so you can jump on the good deals. If shop is a distance from house, consider installing security alarm system with loud siren on building and hard wired small siren inside house. I got all of the pine shavings you see for free on Craigslist also, I had to drive an hour each way, but I got a full size pickup load, enough for me and my friend. You will not hear alarm on building if it sounds at 3:00am, but you will hear small alarm inside house. I needed lumber for cheap, I checked Craigslist, checked the local paper, and then a light went off in my head.
After the rafters were cut I used screws to secure them to the building using the 16 on center studs as anchor points.
I started out gathering scrap lumber, (anything that had been cut or had nails), in 3 days I had most of the framing materials. I stopped at a huge construction site and asked the super if I could get scraps from the dumpster, he said sure and after 3 truckloads I had everything I needed to begin construction.
