The good news is that the necessity of repairing or replacing your current trailer lighting also gives you the option to make things better.
For starters, they have filaments, which can break due to vibration, and cases that can short and corrode. To be legal, trailers are broken down into two sizes—those less than 80 inches wide and those greater than 80 inches. Trailers over 80 inches require a few more lights to define their perimeter, including a trio of red identification lights at the rear and clearance lights on the outer perimeter, typically the fenders. With a new light kit and various supplies in hand, take a moment to lay everything out along your trailer before removing the old lights, or cutting away the wiring harness. Do not, however, strip out the old wiring just yet, especially if you have an enclosed, tubular steel trailer which routes the wiring within for protection. After that, it’s simply a matter of connecting the appropriate wire from the harness to the similarly colored wire at the light itself.
Finally, coat the trailer and tow vehicle wiring connectors with a silicone grease or similar product to reduce corrosion and water intrusion. We use cookies to improve your experience on this website and so that ads you see online can be tailored to your online browsing interests. Sea-Doo’s entry into the trailer market raises some interesting questions about PWC trailers. Galvanizing is an alternative to painting, and promises longer life and resistance to rust.
Absorbing those bumps in the road is the job of your trailer’s suspension, typically leaf springs or torsion beams. Hub bearings are typically protected by grease, packed inside the hub and forced into the bearings to prevent friction and heat build-up. Spring-loaded bearing protectors, like the Bearing Buddy, protect the bearings and keep grease contained, while allowing easy visual inspection of the grease level.
Trailer bunks are most common, as they provide support along much of the entire length of the hull.
Laws vary by state, but typically brakes are required for all wheels on any trailer that grosses in excess of 3000 pounds. Disc brakes use hydraulic pressure to force a pair of brake pads to squeeze against a rotor, located behind the wheel hub. Trailers with drum brakes should have a hose connection to allow flushing the brake’s internal surfaces with fresh water. A trailer winch allows your PWC to be pulled up onto the trailer with relatively little effort, and also serves as a tie-down point for the bow once the boat is in place. Safety chain or cable is designed to run from the trailer tongue to the tow vehicle to prevent accident or injury in the unlikely event your trailer comes off the tow ball. LED lights are considered a vast improvement over low-tech, incandescent bulbs as they offer a far longer lifespan, can be sealed from water intrusion, use less energy, and are, on average, far brighter than incandescent bulbs. Make sure your trailer tires are rated to carry the load of your fully loaded boat and trailer. Sure they look nice and bright when everything is new, but eventually you’ll blow out a bulb or two, find a leak in the housing or just waste an entire weekend tracking down an elusive short or lost ground. Add in the fact that they’ll regularly get dunked underwater, where a leaky housing can spell doom or cold water can cause a thermal shock to a hot bulb, and you’ve got a system prone to eventual failure.
Trailers less than 80 inches are required to feature taillights, turn signals, side marker lights and side and rear reflectors on each side.


Depending upon what came with your kit, you might want to pick up a few butt connectors to connect your wires. Make certain that the wiring is long enough to reach where it needs to go, and light posts match the existing mounting brackets on your trailer.
In this case, clip the plug from the existing harness and then tie the appropriately color-coded wires to those in the new wiring loom. The green wire is for the right turn indicator; obviously it will run down the right-hand side of the trailer.
Next, just simply pull the old wiring out from the rear of the trailer, adjacent to the lights. Protect trailer wiring harnesses from chafe by running the harness through rubber grommets where is passes through the frame of the trailer, and use sufficient clips or other attachments to reduce movement while on the road. Hook up the trailer to the hitch to ground the trailer to the car’s frame, and plug in your lights. It’s strong, its tubular design provides a pathway to protect wiring and possibly brake lines, and it can be painted to match your craft or tow vehicle. Galvanizing involves dipping the steel into a bath of heated liquid zinc; once dry, it forms a silvery coating that resists rust and corrosion and is almost a must in a saltwater environment.
Typically fabricated from I-beams, it’s very strong and lightweight, but offers less protection to wiring and brake lines. An alternative system is oil bath lubrication, which uses a reservoir of oil to continually coat the bearings as they rotate. Manufacturers claim the spring pressure also prevents water from entering the hub when submerged. Hydraulic surge brakes are the most common trailer option, partly because they are far more tolerant of water than their electric alternative. Discs are generally less complicated internally, require fewer adjustments, but more expensive up front. Essentially a system of tubing plumbed to a hose connection affixed to the trailer, a flush kit gets fresh water into areas that would normally be inaccessible to a hose, and greatly reduces the chance of rust and corrosion over time. Typically winches are mechanical, requiring a handle to be cranked to wheel the strap or cable onto the winch barrel.
Chains should be crisscrossed under the coupler, short enough to catch the tongue before it hits the pavement in the event of a failure, and feature beefy S hooks to secure to the cable attachments provided on the vehicle or hitch. Jacks typically feature a wheel at the base to allow the trailer to be moved about and positioned above the hitch ball.
Look at the tire’s Load Index, the last set of numbers following the tire’s size description. Until recently, your average trailer came with incandescent lights, which use bulbs for illumination. LEDs are rated at 100,000 hours of service, compared to an incandescent’s 3,000, have no filaments to break from vibration and are virtually immune to submersion thanks to their permanently sealed, welded polycarbonate cases. A license plate light is also a must; typically, it’s contained within the left taillight housing. The old wiring will act as a guide, pulling the new wiring into position and avoiding a lot of hassle. It needs to be secured to the trailer frame in some fashion, typically where the old ground was located.
Then, have a friend hop in the driver’s seat while you watch the lights at the back of the trailer.


For many of us, the answer is probably just a frame and a set of wheels to get us down the road. Other gear you’ve added to your storage compartments, or any on-trailer storage, also must be considered. Hydraulic surge brakes are activated by the change in momentum caused by the tow vehicle as it decelerates. Disc brakes also feature no enclosed parts, making them far easier to rinse off at the end of the day with fresh water and less likely to suffer from rust and corrosion. Incandescents, however, are not always the best match for the abuse of roads and launch ramps.
LEDs also are noticeably brighter, produce little heat (drastically lowering the risk of thermal shock), and draw less than 15 percent of the current required by incandescents. If you’re using a quality retailer like West Marine or Overton’s, just make sure you get the right size kit – all the necessary lights will be included. If your wires simply run along the outside of the trailer frame, make sure to secure them every 18 inches with heavy-duty wire ties or galvanized clips to prevent dragging or chafing. It may look nice and shiny now, but down the road it too will age, dulling to a not-as-attractive silver finish.
Rollers typically provide easier loading and launching, particularly on gently sloped launch ramps, but often do not support the hull as well as a comparable bunk.
The trailer’s momentum pushes the brake housing forward, which ultimately forces brake fluid out of the master cylinder and into the wheel cylinders, activating the trailer brakes.
Typically ranging from about 80 (a 992 pound load capacity) to 110 (2,337 pounds), make sure the cumulative total exceeds that of your load.
You’ll also need a crimping tool to make your connections, as well as strip the insulation off your wire leads. It should be mounted to the trailer frame, typically in the same location as your former ground. You can also splice a ring connector onto the wire’s end and place it over the mounting bolts so that the ring is pinched between the metal bracket and the nut that secures the light in place. Verify also that your license plate is illuminated and that any side perimeter lights, if required, are also lit when the car’s lights are on.
A solid metal bar is fixed to the trailer frame; at the opposite end, a lever is attached to the axle. Check with your boat manufacturer, as they often suggest a certain type of trailer for best support. It’s the tire’s maximum speed capability, typically between an R-S (106-112 mph) on most trailer tires.
They may also be better for lighter trailer loads, as they don’t require the higher pressure of disc brakes, and often have more surface area on the pads. Many brake experts contend drums are better when the Gross Vehicle Weight (GVW) is under 3000 pounds. The primary disadvantage to drum brakes is that they contain water, possibly resulting in far faster corrosion and failure.
