FIELD OF THE INVENTIONThis invention relates to ear-piercing devices and, more particularly, to an ear-piercing cartridge and stud gun system with a stackable packing box for the cartridge.BACKGROUND OF THE INVENTIONEar piercing is increasingly becoming a commonplace fashion statement.
The "off" amount and percentage simply signifies the calculated difference between the seller-provided original price for the item and the seller's current discounted price.
Estimated delivery dates - opens in a new window or tab include seller's dispatch time, and will depend on postal service selected. If the item comes direct from a manufacturer, it may be delivered in non-retail packaging, such as a plain or unprinted box or plastic bag. Contact the seller- opens in a new window or tab and request a postage method to your location. Delivery times may vary, especially during peak periods and will depend on when your payment clears - opens in a new window or tab. Find out more about your rights as a buyer - opens in a new window or tab and exceptions - opens in a new window or tab. You've read and agree to the Global Shipping Programme terms and conditions - opens in a new window or tab.
Import charges previously quoted are subject to change if you increase your maximum bid amount.
We have blood borne pathogens trainingWith years of experience in a range of different styles & ethnic base shops.
The invention provides an earring cartridge carrying a stud having a post in a stud post holder assembly and a nut in slidably aligned, spaced apart, and oppositely opposed placement so that an ear part may be placed between the post and the nut for piercing wherein a torque-like force is produced on the stud post holder assembly causing the assembly to rotatably open when the earring cartridge is compressed to bring the stud towards the nut for engaging the post with the nut.
The earring cartridge and stud gun system of claim 1 wherein the top surface of the earring jaw has a radial cavity adapted to accommodate the hinged hoop earring stud. The earring cartridge and stud gun system of claim 1 wherein the hinged hoop earring is held within the stud post holder assembly such that the hoop curves away from the stud. The earring cartridge and stud gun system of claim 1 wherein the hinged hoop earring is held within the stud post holder assembly such that the hoop curves towards the stud. The earring cartridge and stud gun system of claim 7 wherein the earring cartridge further comprises a nut jaw retention system comprising: a bottom side of said earring jaw adjacent said bottom channel and defining an opening between an interior said an exterior of said earring jaw, said opening parallel to a length of said bottom side and extending from a rear portion of said earring jaw to a point just past a midpoint between said rear portion and a front portion of said earring jaw, said opening accommodating a hook coupled to said nut jaw introduced into said opening whereby said hook may travel along said opening and may be caught at a forward end thereof at said point just past said midpoint. The earring cartridge and stud gun system of claim 8 wherein the earring jaw further comprises a biasing engagement mechanism for engaging said earring jaw and said nut jaw that also tends to urge said earring jaw away from said nut jaw comprising: a spring post, said spring post coupled centrally to an interior rear wall of said bottom channel, said spring post extending into said bottom channel generally parallel to a bottom side approximately one-quarter the distance between a rear and a front of said earring jaw.
The earring cartridge and stud gun system of claim 9 wherein said earring jaw further comprises: a plurality of ribs, said plurality of ribs present on an exterior of said earring jaw, generally opposite said bottom channel, said ribs providing means by which secure manual engagement may be made of the exterior of said earring jaw.
The earring cartridge and stud gun system of claim 15 wherein said extension means further comprises: a tongue portion, said tongue portion extending from said neck portion and terminating in a hook, said tongue portion descending at an angle from said neck portion whereby said catch may engage a terminal end of an opening present in a bottom side of said earring jaw. The earring cartridge and stud gun system of claim 12 wherein said slidable engagement means further comprises: an elongated portion slidably engaging the interior of said bottom channel. The earring cartridge and stud gun system of claim 17 wherein: said elongated portion defines a bore wherein said bore is defined by first and second nut jaw extensions, said first nut jaw extension extending above said bore and said second nut jaw extension, said first and second nut jaw extensions having oppositely opposed curved sections that serve to retain said biasing means within said bore and that serve to define corresponding gaps between said first and second nut jaw extensions and wherein said biasing means is a spring. The earring cartridge and stud gun system of claim 1 wherein said earring jaw further comprises: two intermediate channels configured to adaptably receive the leg of the terminal member of each half of the stud post holder assembly whereby the legs slide within said intermediate channels when said stud post holder assembly slides in and out of the earring jaw. The earring cartridge and stud gun system of claim 19 wherein the earring cartridge further comprises a flexible tang and a hump juxtaposed with the flexible tang such that when the rear end of the body of the stud post holder assembly moves past the flexible tang, the bases of the terminal members are forced up onto the hump. The earring cartridge and stud gun system of claim 20 wherein the flexible tang is shorter than the legs of the terminal members. The earring cartridge and stud gun system of claim 21 wherein the flexible tang is moldably attached to the hump. The earring cartridge and stud gun system of claim 22 wherein the hump is attached to the upper surface of the nut jaw extension. The earring cartridge and stud gun system of claim 23 wherein said flexible tang is flared upward to engage an underside of said post holder assembly so as to better open said assembly once said assembly moves past the tang.
The earring cartridge and stud gun system of claim 1 further comprising an alignment system for the two halves of the stud post holder assembly comprising a peg jutting out of the outer surface of one body and the other body having a cavity sized to adaptably receive the peg such that when the two halves of the stud post holder assembly are assembled together in alignment the peg is received within the cavity.
The earring cartridge and stud gun system of claim 26 wherein the stackable packing box further comprises: a conforming top and a lid wherein either one of the conforming top or the lid has a plurality of pegs and the other has a plurality of holes adapted to receive the pegs whereby when a first box is placed on top of a second box the pegs in the first box fit within the holes in the second box thereby allowing the packing boxes to be stacked.
The earring cartridge and stud gun system of claim 29 further comprising a stackable packing box for housing the earring cartridge during transport and storage, said box being congruently configured to said earring cartridge and conformably accommodating said earring cartridge and being sealable to medically seal said earring cartridge within it.
The earring cartridge and stud gun system of claim 30 wherein the stackable packing box further comprises: a conforming top and a lid wherein either one of the conforming top or the lid has a plurality of pegs and the other has a plurality of holes adapted to receive the pegs whereby when a first box is placed on top of a second box the pegs in the first box fit within the holes in the second box thereby allowing the packing boxes to be stacked.
The earring cartridge and stud gun system of claim 32 whereby said earring cartridge is used by placement within said cradle, said cradle receiving and removing said earring cartridge from said stackable packing box to provide and present said stud and said nut in aligned position for piercing said body part without the necessity of handling said earring cartridge with the hands of the operator. The earring cartridge and stud gun system of claim 34 further comprising: a stackable packing box for housing the earring cartridge during transport and storage, said box being congruently configured to said earring cartridge and conformably accommodating said earring cartridge and being sealable to medically seal said earring cartridge within it. The earring cartridge and stud gun system of claim 36 wherein the stackable packing box further comprises: a conforming top and a lid wherein either one of the conforming top or the lid has a plurality of pegs and the other has a plurality of holes adapted to receive the pegs whereby when a first box is placed on top of a second box the pegs in the first box fit within the holes in the second box thereby allowing the packing boxes to be stacked.
In the past, ear piercing has been a procedure performed by a doctor or other medical practitioner, such as a nurse. If you reside in an EU member state besides UK, import VAT on this purchase is not recoverable.
Import charges previously quoted are subject to change if you increase you maximum bid amount. The rotatable opening of the stud post holder assembly facilitates the disengagement of the assembly from the earring stud after the stud has connected to the nut, eliminating the need to touch the ears of the customer to confirm the stud-nut connection or to remove the assembly after the ear piercing is completed. A vertically stackable packing box maintains a sterile environment in which an earring cartridge with a pierced-ear earring stud may be transported and stored. 19, 1998, all of which are incorporated herein by this reference.The Reil '774 Patent describes the latest ear-piercing system in the evolution towards developing a simple, easy to use, safer, hygienic, user-friendly, manually operated device. The stud is held within a stud post holder assembly (also called “pierced-ear earring cartridge” in the Reil '774 Patent), which is a module that disassembles into two pieces. One of these pieces has a frangible and breakable tab at its rear.Although, the '774 Patent describes a simple, easy to use ear-piercing system, when it is used to pierce an ear, the two pieces of the stud post holder assembly may stay attached to the stud and sometimes require manual removal from the earring. Further, on occasions when the two pieces come off the stud, they fall out of the assembly, sometimes into the ear or onto the body of the subject whose ears are being pierced and at other times onto the floor.Moreover, the reliance of tie '774 Patent on the frangible tab has design limitations.


First, the breaking of the tab causes an unwanted noise that is often a source of distress or concern for the customer. Second, the use of the frangible tab leads to only discrete control over the ear-piercing process. In the invention of the '774 Patent, when the earring assembly is squeezed, either holding it in a hand or mounted in an ear-piercing gun, the presence of the frangible tab implies that once the earring assembly is squeezed to the point of breaking the tab, the ear is pierced automatically. The rotatable opening of the stud post holder assembly facilitates the disengagement of the assembly from the earring stud after the stud has connected to the nut, eliminating the need to touch the ears of the customer to confirm the stud-nut connection or to remove the assembly after the ear piercing is completed.In a preferred embodiment, the earring cartridge comprises a nut jaw for holding the nut and an earring jaw for holding the stud post holder assembly, which carries the stud. The assembly is in two halves with each half having a front stud head adaptor, a main body and an L-shaped terminal member having a base and a leg.
In particular, the present invention seeks to provide an ear-piercing system in which the stud holding module separates from the stud cleanly as soon as the ear is pierced. Further, the present invention provides a system whereby the components of the stud holder module remain within the earring cartridge after an ear is pierced. This eliminates the possibility of the module components falling into the ear or body of the subject being pierced or onto the floor, forcing the ear piercer to look for them following the ear piercing operation.It is another object of the present invention to provide a higher level of accuracy for ear-piercing by means that are more controllable and more expertly handled by persons without the requirement of a high degree of training. 2 is a side cross-sectional view of the ear-piercing cartridge stud gun taken along line 3—3 of FIG. 3 is a perspective view of the associated ear-piercing cartridge and stud gun when fitted to each other;FIG.
7 is a top view of the earring cartridge as the stud is being driven toward the clutch;FIG. 7 and 8, showing the sequential action of the stud holders opening up but being retained to prevent reuse of the earring cartridge;FIG. 13A and 13B show two alignments of a hinged hoop earring.DETAILED DESCRIPTION OF THE PREFERRED EMBODIMENTSThe system of the present invention involves the use of an earring-cartridge that provides better control over, optimizes operation and, therefore, is safer use of an earring cartridge. The earring-cartridge stud gun of the invention and the system incorporating its use provides means by which precise control can be exerted and maintained over the earring cartridge while allowing the stronger palm muscles of the hand to drive the ear-piercing process. The earring cartridge of the present invention provides a stud post holder assembly that opens rotatably releasing the stud cleanly and retaining the assembly components within the cartridge when an ear is pierced.Additionally, the invention uses sterile stackable packing means for convenience of storage and to create and maintain a sterile environment for the earring cartridge, the stud post holder assembly, and the earring during transport and storage. The stackable packing also provides sterile means by which the caning cartridge will be maintained in a sterile environment until use, allowing the manipulation and articulation of the earring cartridge without requiring direct contact with human hands or other contaminated and contaminating surfaces. By sterilizing the contact area between the earring-cartridge stud gun and the earring cartridge, a completely sterile environment can be maintained for the instruments used for the ear-piercing process.Generally, the figures show the construction and operation of the earring-cartridge stud-gun system. 1 and 10, the earring-cartridge-and-stud gun system 10 of the present invention is comprised of the earring-cartridge stud gun 12, the earring cartridge 14, and the earring cartridge stackable box (FIG.
The earring cartridge 14 with the earring stud P and nut N fits within the stackable box 16 which is constructed to conform to the exterior shape of the earring cartridge 14. The stackable box 16 is sealed by removable medical-grade paper 18 adhesively sealed to the top container of the stackable box 16.
After sealing one or more of the blister packs, sterilizing gas may be used to sterilize the stackable box 16 so that the interior thereof and any contents, including the earring cartridge 14 and earring stud P and nut N are sterilized and it stays sterile until used. During transport and storage, the sterile environment created inside the stackable box 16 is maintained until the seal is broken by removal of the peelable paper backing 18 just prior to the use of the earring cartridge 14 during the ear-piercing process.The earring cartridge 14 fits within the earring-cartridge stud gun 12 so that a person's entire hand, not just the fingers, may be used to wield and control the pierced-ear earring prior to and during the ear-piercing process.
The cartridge is also provided with a plurality of ribs 180, 181 on its outside surface so that the cartridge itself may be used without the stud gun for ear piercing.The earring-cartridge stud gun 12 is shown in FIGS. 2-3 wherein two inter-fitting portions comprise the earring-cartridge stud gun 12: the grip 20 and the plunger 22. The plunger 22 fits within the grip 20 and slidably travels there through a generally short distance, namely, that distance necessary to pierce the ear with the stud portion of the pierced-ear earring.
That distance of travel is approximately one-half inch and the plunger 22 is easily controlled by the hand.
The length of the plunger-grip assembly is approximately two-and-one-half inches taken along the line 5—5 as shown in FIG. Oppositely disposed stud-gun spring posts 26a, b serve to hold spring 24 in place between the grip 20 and the plunger 22 in a normally-opposed position.
The plunger 22 is held in captive association with grip 20 as set forth in more detail below.The plunger 22 may be hollow in order to conserve cost, weight and to allow for greater ease of manufacturing. On the inside of the plunger 22 within the grip 20, lower abutment stop 28 and an upper abutment stop 30 serve to limit the forward travel of plunger 22 into the interior of the grip 20.
The distance between the contact surfaces of the abutment stops 28, 30, and the grip 20 is approximately one-half inch.
The abutment stops 28, 30 may be formed of the same material as the plunger 22 and may be molded as an integral unit with plunger 22.Upper abutment stop 30 is formed in an L-shape (in cross section) so as to accommodate the traveling portion 40 of the cradle 74 provided by the earring-cartridge stud gun 12 for the earring cartridge 14.
The traveling portion 40 has a depending projection 42 that fits within the notch 44 provided between the upper abutment stop 30 and the plunger 22. Tongue 46 projects laterally forward and away from the plunger 22 to act as an additional travel limiting stop as will be seen.
A cradle backstop 48 serves to provide the retaining support and abutment at the back of the earring cartridge 14 once it is fitted into the earring-cartridge stud gun 12 and more specifically, cradle 74 thereof.Traveling portion 40 is molded as one piece with plunger 22 or may be welded thereto so as to be integral with plunger 22.
The traveling portion 40 travels with the plunger 22 due to its connection with the upper abutment stop 30 via the depending portion 42. Along with the plunger 22, the traveling portion 40 slidably travels along any surface of the grip 20 with which it may come into contact except where abutment occurs.The grip portion 20 has a front-curved surface 60 adapted to fit against the fingers of the hand. In conjunction with the rear-curved surface 62 of the plunger 22, the portion of the earring cartridge stud gun 12 engaged by a person's hand fits comfortably within the hand due to the complementary curved surfaces 60, 62. The grip portion 20 is approximately two inches in height, about three inches in overall width, and defines upper slot 64 through which the cradle backstop 48 travels.
An abutment or end wall 66 of the slot 64 of the grip portion 20 serves to prevent the rearward travel of the cradle backstop 48 beyond that shown. The abutment 66 between the cradle backstop 48 holds the plunger 22 in sliding association with the grip 20, even though biasing means 24 normally urges them apart.Projecting forwardly from the top of the grip 20 is a cradle extension 70 that terminates in a cradle forestop 72.
The area defined between the cradle forestop 72 and the cradle backstop 48 serves to define a cradle 74 within which the earring cartridge 14 may fit and be telescopically compressed during the ear-piercing process. Provided beneath the upper surface 76 and above the lower surface 78 of the cradle extension 70 is a tongue groove 80. As the tongue 46 is captively retained between the upper surface 76 and the lower surface 78 of the cradle extension 70, greater stability and alignment is provided during the ear-piercing process as the cradle 74 maintains its relative geometry and shape during the piercing process.In order to provide additional support to the cradle extension 70, integrally molded cradle extension support 90 extends forward of the tongue groove 80 and terminates below the forestop 72.
The cradle extension support 90 provides additional support to the cradle extension 70.The interior of the cradle 74 has additional means by which the earring cartridge 14 is held and maintained in position.
Thus, oppositely disposed across the cradle 74 adjacent the forestop 72 are two side supports 100a, b. The cradle side supports 100a, b project upwardly approximately an eighth of an inch and provide additional side securement and positioning for the earring cartridge 14. The interior of the backstop 48 and forestop 72 may have notches or ridges by which to engage the ribs 180, 181 present on the earring cartridge 14.
In one embodiment, a small extension or finger (not shown) may extend upwardly from the upper surface 76 of the cradle extension 70 adjacent the forestop 72 to frictionally engage the front end of the earring cartridge 14. Both the backstop 48 and the forestop 72 may have side flange projections 82 to better engage and secure the earring cartridge 14 in the cradle 74.As shown in FIG. The earring cartridge fits within the cradle 74 provided by the earring-cartridge stud gun 12.Generally, the invention's earring cartridge 14 comprises a stud post holder assembly 116 for holding the stud P, an earring jaw 112 for movably carrying the stud post holder assembly 116, and a nut jaw 114 for alignedly holding the nut N opposite the stud P, the nut jaw 114 having a nut jaw extension 154 for slidably engaging the nut jaw 114 with the earring jaw 112. The nut jaw extension 154 and the stud post holder assembly 116 interact to produce a torque-like force on the stud post holder assembly 116 causing it to rotatably open upon the assembly moving through the earring jaw 112 when the earring cartridge is compressed to bring the earring jaw 112 towards the nut jaw 114 for engaging the post with the nut. The nut N of the present invention is preferably provided with a backing shield (not shown) to prevent the end of the stud post from contacting a subject's body after the stud post is engaged by the nut.Referring to FIGS.


5-9, the stud post holder assembly 116 for holding the stud is in two halves, each half comprising main body 113, 115, front stud head adaptors 117, 119 attached to the front side of the body and L-shaped terminal members with legs 125, 127 and bases 204, 205 attached to the rear side of the body 113, 115. The front stud head adaptors 117, 119 are recessed to receive the stud head and form a through hole adapted to hold a hinged hoop earring stud (not shown). The top surface of the earring jaw has a radial cavity such that a stud post holder assembly carrying a hinged hoop can be accommodated in it.
Enough room is provided so that a hinged hoop earring can be held within the stud post holder assembly such that the hoop can curve away from the stud (FIG. 13B).The stud post holder assembly 116 fits within a top channel 201 of the earring jaw 112.
The body of each half of the stud post holder assembly 116 is held within the top channel such that the stud post holder assembly 116 can slide in and out of the earring jaw 112.
The bottom channel 120 serves as a guidance and alignment means for the nut jaw extension 154 with its base 152.The earring jaw 112 further comprises a nut jaw retention system comprising a bottom side 152 of the earring jaw 112 adjacent the bottom channel and defining an opening 155 between an interior and an exterior of the earring jaw 112.
The opening 155 is parallel to a length of the bottom side and extends from a rear portion of the earring jaw 112 to a point just past a midpoint between the rear portion and a front portion of the earring jaw 112 and accommodates an extending tongue 168 with a hook coupled to the nut jaw 114. When the tongue 168 is introduced into the opening 155 the hook may travel along the opening 155 and may be caught at a forward end thereof at the point just past the midpoint.The earring jaw 112 also comprises a biasing engagement mechanism for engaging the earring jaw 112 and the nut jaw 114 that also tends to urge the earring jaw 112 away from the nut jaw 114.
Further, the nut holder may comprise a block, 191 coupled to the support means and defining first and second nut grooves within which an earring nut N may fit.
A plurality of ribs 181 is present on an outward facing portion of the upright portion opposite the void, and provides means by which secure manual engagement may be made of the exterior of the nut jaw 114.The extension means comprise a base portion which is coupled to the nut holding means. The base portion has a width approximately the same as the width of the earring jaw 112 to provide means by which the nut holding means may be sturdily supported and provides a means by which the nut jaw 114 may be engaged by the earring jaw 112 thereby obstructing further slidable travel of the nut jaw 114 into the earring jaw 112. Further, a neck portion is coupled to the base portion and has a width approximately the same as a width of the bottom channel 120 so that the neck portion may slide into the bottom channel 120. The extension means may further comprise a tongue portion 168, which extends from the neck portion and terminates in a hook. The tongue portion 168 descends at an angle from the neck portion whereby the catch may engage a terminal end of the opening 155 present in a bottom side of the earring jaw 112.In one embodiment, the slidable engagement means comprise an elongated portion slidably engaging the interior of the bottom channel. The elongated portion may define a bore wherein the bore is defined by first and second nut jaw extensions, the first nut jaw extension 169 extending above the bore and the second nut jaw extension 170. The first and second nut jaw extensions have oppositely opposed curved sections that serve to retain the biasing means within the bore and that serve to define corresponding gaps between the first and second nut jaw extensions and wherein the biasing means is a spring (not shown).The earring jaw 112 may further comprise two intermediate channels 208 configured to adaptably receive the leg 125, 127 of the terminal member of each half of the stud post holder assembly 116 whereby the legs slide within the intermediate channels 208 when the stud post holder assembly 116 slides in and out of the earring jaw 112. The earring cartridge also comprises a flexible tang 160 and a hump 161 juxtaposed with the flexible tang 160 such that when the rear end of the body of the stud post holder assembly 116 moves past the flexible tang 160, the bases 204, 205 of the terminal members are forced up onto the hump 161. In one embodiment, the length of the flexible tang 160 is shorter than that of the legs 125, 127 of the terminal members. When it does not include a stud gun, the earring cartridge alone may be used for ear piercing. 7 and 8, it will be seen that the stud or earring post P is releasably held by oppositely disposed stud-holder halves 113 and 115. Each of the stud-holder halves 113 and 115 have a front stud-head recess 117 and 119, respectively, and a rearward, rectangular portion 121 and 123, respectively; which terminate in termini 125 and 127, respectively. Rectangular portions 121 and 123 are adapted to ride within top channel 118 of cartridge 116 with the retained stud or post P retained in captive relationship there between.The operation of the earring cartridge is as follows. Normally, the earring cartridge sprig 142 or other biasing means forces the nut jaw 114 away from the jaw 112 as far as the bottom slot and hooked tongue 168 will allow. Ample room is provided between the nut jaw 114 and the earring jaw 112 for the insertion of an eat (not shown) to be pierced. Once the ear is placed between the nut jaw 114 and the earring jaw 112, and necessarily between the earring stud or post P and the earring nut N, the earring-cartridge stud gun 12 is squeezed to compress the earring cartridge 14. This compresses the earring cartridge 14 to bring the bases 204, 205 of the L-shaped terminal member legs 125, 127 over the hump causing a torque-like force to be applied on die two halves of the stud post holder assembly 116.At this point, if the ear piercer is satisfied and ready to pierce the ear, he firmly squeezes the stud gun 12 causing the tang 160 to move past the back end of the assembly 116, the flexible tang 160 is free to rise up and above the plane of the earring cartridge bottom.
This drives the earring stud or post P through the ear and into the flanged aperture and through the curled springs of the earring nut.
The box 16 allows and maintains sterilization of the earring cartridge 14, and the pierced-ear earring E.As shown in FIG. 10, the earring cartridge box 16 is constructed to conform to the top of the earring cartridge 14. The conforming top 300 of the box 16 conforms to the top exterior of the earring cartridge 14 for a close but not constricting fit.
Internal indentations 301, 302 provide gripping means by which the top 300 grips the earring cartridge 14 inside.
As the earring cartridge 14 may take a variety of shapes, the shape achieved by the conforming top 300 of the box 16 may also take the same variety of shapes including hinged hoops in order to accommodate the earring cartridge 14. 11A and 11B, respectively.The packing box design allows the cradle 74 of the earring-cartridge stud gun 12 to fit within the box 16 past the flange 304. This allows the earring-cartridge stud gun 12 to engage the earring cartridge 14 and remove it from the box 16.
This provides means by which the sterile nature of the earring cartridge 14 and the pierced-ear earring E may be maintained once the seal on the earring-cartridge box 16 has been broken.
Additionally, the earring cartridge 14 may be reinserted back into the box 16 after the ear-piercing process has been performed by fitting the earring-cartridge box 16 over the earring cartridge 14 and removing the earring cartridge 14 from the cradle 74.During manufacture and prior distribution, the earring cartridge 14 is fitted with a pierced ear earring E within a stud post holder assembly 116. The earring cartridge is then fitted within the conforming top 300 of the earring cartridge box 16. The bottom of the earring cartridge 14 is above the flange 304 and within the confines of the box 16.
Sterilizing gas or the like may be introduced into the confines of the earring-cartridge box 16 so as to sterilize its entire contents and any exposed surfaces, including the earring cartridge 14 and the pierced-ear earring E. Medical-grade Tyvak paper backing or the like (not shown) may be adhesively or otherwise sealingly attached to the flange 304.
Where sterilizing gas is used, it is then intentionally trapped within the earring-cartridge box 16 to preserve and maintain the sterile environment previously established. Obviously, other sterilizing procedures maybe used.The bottom of the box 16 is sealed with a lid 310, which is shown in plan and elevation views in FIGS.
The lid 310 snaps shut over the flange 304, thereby providing protection for the paper backing used to seal the conforming top 300. The lid 310 is provided with pegs 311 which can fit into corresponding holes 305 of the conforming top of another packing box. Thus, this peg and hole arrangement can be used to vertically stack the packing box on top of each other.Once the lid is snapped onto the flange of the top 300, the sealed, earring-cartridge box 16 may then be transported and stored until ready for use, maintaining the earring cartridge 14 and its pierced-ear earring E in a sterile condition until ready to useIn operation, the earring-cartridge box 16 with sterilized earring cartridge 14 is used in conjunction with the earring-cartridge stud gun 12 as follows. This exposes the bottom of the earring cartridge 14 and provides access to the cradle 74 to the interior of the earring-cartridge box 16. The cradle 74 of the stud gun 12 is then brought into the confines of the earring-cartridge box 16 to engage the bottom of the earring cartridge 14. Once the cradle 74 has securely engaged the earring cartridge 14, the box 16 is then removed from the top of the earring cartridge 14.
Upon full compression, the ear has been pierced; and the earring post P has engaged the nut N. Pressure is then released from the hand upon the earring-cartridge stud gun 12, the pierced-ear earring cartridge halves 113 and 115 (FIG.
