QuestionQUESTION: I recently added another 0 gauge train, running on it's own 0-27 track, to my Christmas scene. I'm assuming by what you're saying that both wires of each lock on go directly to the power supply and not to each other. Yes, the wires go from the power supply to each Lock-on and not daisy chained to each Lock-on. For our O Gauge Model Railroad Layout Project for a Spare Bedroom, we used a way to connect power to the track that is totally invisible from above – we soldered the power wires onto the bottom of the rail. We start out with two lead wires about 18 inches each: red for the center “hot” rail, and black for the outside “ground” rails. Just as you must strip the insulation from the wires before inserting them into the Lionel CTC Lockon, you must strip them before soldering (Figure 3). While you can strip wire with an Xacto knife by lightly rolling it back and forth until it cuts through the plastic insulation, and then removing the piece of insulation by sticking your fingernail into the cut and pulling with your finger and thumb, I use a handy automatic wire stripper (Figure 4) that grabs the insulation, cuts it, and then pulls it off. As shown in Figure 5, we used a “third hand” with an alligator clip at the end of it to hold the red “hot” wire in contact with the center rail while we heated the rail at the tip of the wire with a small soldering iron. Repeat the process with the black “ground” wire, attaching it with the bare wire running the same direction as the other lead, and close to the part of the track section where the other lead is attached, as shown in Figure 6. After the solder joints have cooled, it’s a good idea to check their electrical conductivity with a multi-meter. On the other end of the soldered leads, we will install spade connectors, as shown in Figure 8. Next we drilled a hole through the roadbed and subroadbed where the wires will be when the track is attached to it.
The easiest way to connect these to the power wires coming from the transformer is to just drive two screws part of the way into the benchwork, place the spade connectors from the track leads and the transformer leads under the head of the screw, and lock them together by tightening the screws down on the spade connectors, as shown in Figure 11. We will, instead, be using barrier block terminal strip connectors where we need to make connections throughout the O Gauge Model Railroad Layout Project for a Spare Bedroom. The track power leads connect to one side of the terminal strip, and the transformer power leads (note we used the same color wire to visually confirm which wire needs to connect to which) to the other side of the terminal strip.


The "off" amount and percentage simply signifies the calculated difference between the seller-provided original price for the item and the seller's current discounted price.
Contact the seller- opens in a new window or tab and request a shipping method to your location. Which leaves us with the packing work and all of the responsibility to see to it that you receive your item in mint condition in a timely manner.
You have read and agree to the Global Shipping Program terms and conditions - opens in a new window or tab. Import charges previously quoted are subject to change if you increase you maximum bid amount.
It is a very large rectangular layout about 6 ft by 8 ft, with the train running on the outer edge. So you should have 4 wires total coming from the throttle, 2 wires together from each side of the throttle control portion of the power pack as shown in the diagram below. If you find something of value here, please "pay it forward" and help us keep the site operating by a secure donation through PayPal (PayPal account is not required), or by shopping with our advertisers. These handy devices clip onto O Gauge tubular model railroad track (Figure 2) to bring the power from your transformer to your trains. Even if you’ve never soldered before, this technique is easy, eliminates the need for Lionel CTC Lockons, and reduces the chances a wire will come loose from the rail and break electrical contact.
You can use any color you like, just be consistent so you don’t have to remember later which wire is soldered to which rail, as you would have to remove the track from the roadbed to find out.
This tool makes short work of the many connections we will need to make in wiring our O Gauge Model Railroad Layout Project for a Spare Bedroom. A soldering iron is another inexpensive tool that will come in very handy not only on this project, but many others around the house. Better to find a bad solder joint now than after the track has been screwed down to the roadbed!
While soldering gives you the sturdiest joint, we will be making our next connections under the benchwork, working over our heads, a situation in which using a soldering iron is just asking for a hot drop of liquid solder to drop on you. Because we are working with low voltage, you can get away with this type of connection, however, we DO NOT recommend this method, as it would be easy for a stray wire to short circuit this setup. As shown in Figure 12, these handy little devices have a plastic base with plastic walls between the connections to keep them from short circuiting. A metal bus connects the left and right connector screws so you get good current through your connections. If you reside in an EU member state besides UK, import VAT on this purchase is not recoverable.
Uses no current except when actually in use so any number of these can be used in your layout. They provide a sturdy connection with good electrical contact, but they stick out like a sore thumb, especially if you plan on ballasting the track with gravel.


A simple matter of loosening a couple screws, unless you have already ballasted the track, in which case, much prying and cursing will be involved. Once the rail and wire get hot, touch a thin rosin-core solder wire to the rail and the end of the bared wire away from the soldering iron. Only one black “ground” wire needs to be attached, as the metal ties of the track create an electrical connection between the two outer rails. Set the meter to read electrical resistance (measured in Ohms), touch one meter lead to the far end of the wire you just soldered on, and the other down the track section a bit on the rail to which that wire is soldered, as shown in Figure 7. Also, a soldered joint is a permanent joint, so any changes to the wiring later would require wire cutters.
If you feed them through the hole one at a time you can get away with using a slightly smaller hole than you would need to cram them both through at one time. We will be using a lot of these devices for connections around the benchwork of our O Gauge Model Railroad Layout Project for a Spare Bedroom. They also can come loose if something hits them, or if, over time, they just lose their springiness they can slip off the track, or the wires slip loose from the terminals. We are using heavier wire for our leads than that supplied with the lockon, which looks to be about 22 gauge. This makes sure the heat of the wire and rail, not the soldering iron, is what causes the solder to melt, ensuring a good solder joint. Small fiber or plastic shims between the metal tie and the center rail keep it electrically isolated from the outer rails. In keeping with our modular benchwork design, the spade connectors will allow us to disassemble or change wiring later without difficulty of cutting and resoldering.
What you end up with after the track is attached to the roadbed is dangling power leads under the benchwork as shown in Figure 10.
If the solder is melted by the soldering iron before the rail and wire are hot enough, you may get a “cold” solder joint that doesn’t conduct electricity well, and is subject to breaking loose. In the photo, the black meter lead had not quite touched the center rail when the camera shutter fired, but when it did, the needle shot to the right side of the meter, indicating there was no impedance in the connection. To attach the spade connectors to the ends of our leads, we use a crimping tool as shown in figure 9. When the solder begins to melt, the rosin-core flux will cause the melted solder to be drawn into the joint. This tool works much better than pliers, as it has teeth than pinch into the metal of the spade connector rather than just crushing it, making for a very secure joint. Once the joint is filled with solder, remove the solder wire and soldering iron and let it cool.
