The basic setup is a web server on the Raspberry Pi, a relay board to switch live voltage and some web code to allow anybody anywhere to turn the lights on and off.
The electronics themselves are pretty simple, a bridge rectifier takes the DCC track power and converts it to DC. In other news I have a new office and have a section of desk specifically set aside for making models.
Daryl Kruse's N scale layout models the modern-era Union Pacific Geneva Subdivision in northern Illinois.
If you are already a registered user of Model Railroader Video Plus you must log in to your account to view this video. Sign up for the Model Railroader Video Plus newsletter to receive special offers from MRVP and its marketing partners. The one disadvantage to the scheme is that it does not actually give the operator any feedback as to whether or or not the Turnout has been thrown because it only latches the last momentary toggle switch position. Power Supply #1 is a 12 vdc, 1 amp wall-wart type or equivalent, that is used to energize the twin coil machines (Turnouts). Power Supply #2 is a 12 vdc, 1 amp wall-wart type or equivalent, that is used as a power source for the Latch Network. The important thing to remember is that the Output of the Latching Network (Q) will hold or memorize the last state (SET or RESET) that was last toggled to by S1. The Latching Network can be packaged as part of the Control Panel with or without an enclosure.
In the figure below it can be seen that U2 is wired in a similar fashion to U1, except that it reflects being used with Turnouts 5 through 8.
In the figure below it can be seen that U3 is wired in a similar fashion to U1, except that it reflects being used with Turnouts 9 through 12 and it uses connector J2 on the Project Box. In the figure below it can be seen that U3 is wired in a similar fashion to U2, except that it reflects being used with Turnouts 13 through 16 and it uses connector J2 on the Project Box.
In the above figure, resistors R3 and R4 are each about 750 ohms each if the Signal Head LEDs are also used.  This is because we have pairs of diodes in parallel so that the overall circuit draws twice the current. In this MRVP exclusive video, Contributing Editor Andy Sperandeo uses MR magazine's HO scale layout to demonstrate six helpful tips aimed at making you a better crew member during your next layout operating session.
If you are already a subscriber to Model Railroader Video Plus you must log into your account to view this video.


There is a vinyl conversion on some Mk4s to a Night Star set (back in the day Eurostar services were going to run across the whole of the UK, Night Star was going to be a sleeper service from the UK deep into Europe but it never happened). The highest level will be a high speed line, possible without a station, for the Eurostar and maybe an ICE3.
A bit of a crossover from the day job and a result of some work I did a while ago I wondered about controlling some of the secondary systems using a web interface. Bog standard Raspberry Pi, a breadboard to break out the outputs and an optical relay board to stop the inevitable wiring cockups blowing the smoke out of the Pi. I am going to sort a better UI for the eventual loft layout, probably with a schematic diagram of the buildings and lights within. A capacitor smoothes the voltage and an LED with built in resistor and flashing unit makes the light. Once it gets power and a consumer unit I will refill the etching tank and have another go at sorting that out. Photos of real buildings and sketches are useful to keep things vaguely realistic but as I model imaginary locations the only real pressure is to make things I like. Maybe the Kestrel houses will make a little Kestrel village tucked at the back when, or if, I get a nice big train shed at the bottom of the garden. A couple of the detailed scenes on Daryl's model railroad include Proviso Yard and a Mississippi River crossing. As either coil is energized by the application of the PS#1 Return line via momentarily toggling Switch S1 a SET or RESET Signal is created and routed to the Latching Network. Each Signal Head is generally made up of one green LED and one red LED.  The can be wired in parallel to the corresponding LEDs on the Control Panel. You can save some money by buying existing Signal Heads and removing the existing light bulbs and replacing them with LEDs. Coming from an "old head" like Andy, who's operated on hundreds of model railroads, you can trust that following these techniques will help get you invited back for more fun!
My full length Eurostar might finally have somewhere to stretch its legs and the three fully sound equipped Pendolinos from will also get a suitable gallop and station. The middle level will be a four track mainline vaguely like the WCML so allowing pretty much anything to run. Combined with a Raspberry Pi for my 40th from Monsieur Morey I now have something approaching a working prototype.


It was the only one I had and given it just drives an LED it runs for about 5 minutes after the power is off. The rectifier also does a good job of preventing the capacitor feeding back into the track and causing issues for the DCC.
The spray booth is already in the shed but needs power and the extraction linked to the outside world. It is possible to fit four of these Integrated Circuits into a Radio Shack Project Enclosure (7 x 5 x 3), giving one the capability to control sixteen turnouts.
The Detailed Schematic Information below reflects an actual design to control 16 turnouts (4 Chips to control 16 Turnouts packaged in a Project Enclosure with the following 37 pin connectors for interface to the Control Panel and the Track Signal Heads. Refer to the figure below  and simply wire the positive side of the Red LED on the Control Panel to the positive side of the RED LED on the Signal Head; likewise wire the negative side of the Green LED on the Control Panel to the negative side on the Signal Head. Wiring up the relay board was simply a case of finding a relay board on eBay and then an example of it being wired on YouTube.
On the plus side because the wagon is quite light it does”t pick up effectively so it works ok. I have resprayed and vinyled two Farish examples but the running is not great and the DCC conversion is far trickier. Either coil is energized by the application of the PS#1 Return line via momentarily toggling Switch S1 to either one side or the other. If a SET is selected via S1, then the input to resistor R1 becomes a Logic zero (12 vdc Return) and the RESET input to R2 remains at a Logic one (+12 vdc). So the next thing to add is a decoder and speaker to the dummy and maybe to the loco as well. If a RESET is selected via S1, then the input to resistor R2 becomes a Logic zero (12 vdc Return) and the SET input to resistor to R1 remains at a Logic one (+12 vdc).
It also interfaces U1 and U2 to the Track Signal Heads on the layout via the Main Front Panel LEDs. I am tempted to stick with a sound decoder in the dummy unit and a lenz mini gold in the loco.
